Nominal diameter: DN100 ~ 1000mm
Nominal: PN0.1MPa
off time: one second
medium temperature: -20 ~ 180 ℃
ambient temperature: -20 ~ 60 ℃
First, DMF-type electromagnetic gas safety shut-off valve Description :
DMF-type electromagnetic gas safety shut-off valve manufactured by the factory new generation of new products. Electromagnetic
gas safety shut-off valve not only overcome the current domestic
commonly used electric shut-off valve cut off the slow, complex control
and other shortcomings, but also in the power outage can immediately cut
off gas to ensure the safety of production. DMF-type
electromagnetic gas safety shut-off valve is mainly composed of a
combination of electromagnetic starter and butterfly valve with good
sealing performance. The utility model has the
advantages of simple structure, convenient operation, reliable work,
fast cutting speed and good sealing performance. Seal is generally oil-resistant rubber, PTFE seals can also provide special products.
Third, DMF-type electromagnetic gas safety shut-off valve size table:
DN | D | D1 | D2 | L | L1 | L2 | H | b | Z-φd |
100 | 205 | 170 | 145 | 120 | 360 | 250 | 550 | 14 | 4-18 |
150 | 260 | 225 | 200 | 145 | 410 | 250 | 590 | 16 | 8-18 |
200 | 315 | 280 | 255 | 145 | 465 | 250 | 640 | 18 | 8-18 |
250 | 370 | 335 | 310 | 180 | 520 | 250 | 690 | 22 | 12-18 |
300 | 435 | 395 | 362 | 180 | 580 | 300 | 740 | 22 | 12-23 |
350 | 485 | 445 | 412 | 200 | 630 | 300 | 790 | 22 | 12-23 |
400 | 535 | 495 | 462 | 200 | 680 | 300 | 840 | 22 | 16-23 |
450 | 590 | 550 | 518 | 200 | 740 | 300 | 880 | 24 | 16-23 |
500 | 640 | 600 | 568 | 270 | 780 | 300 | 930 | 24 | 16-23 |
600 | 755 | 705 | 670 | 270 | 895 | 400 | 1020 | 24 | 20-25 |
700 | 860 | 810 | 775 | 270 | 1010 | 400 | 1100 | 24 | 24-25 |
800 | 975 | 920 | 880 | 270 | 1125 | 400 | 1190 | 26 | 24-30 |
900 | 1075 | 1020 | 980 | 270 | 1225 | 400 | 1280 | 26 | 24-30 |
1000 | 1175 | 1120 | 1080 | 300 | 1345 | 400 | 1360 | 26 | 28-30 |
